UVITEC – Cambridge
74/225
B
AND DETECTION ON THE PROFILE
The profile is calculated based on the average intensity of each row of pixels across
the specified width of the lane. A lane profile provides a visualisation of the intensity of
the bands. Bands are represented by peaks.
You can add or remove bands by clicking directly on the profile. To proceed, select
the cursor type:
The linear cursor has the shape of an arrow ( )
The rectangular cursor has the shape of a square ( )
Place the cursor at the chosen profile location and click. The detection line is
automatically added or removed.
