Vacon 100X series User Manual

vacon • 87 Parameters
6
6.1.10 Group 3.9: Protections
6.1.10.1 Group 3.9.1: General
P3.8.6 Superv2 Mode 0 2 0 1436 See P3.8.2
P3.8.7 Superv2 Limit -50.00 50.00 Varies 40.00 1437 See P3.8.3
P3.8.8 Superv2 Hyst 0.00 50.00 Varies 5.00 1438 See P3.8.4
Table 72. General protections settings
Code Parameter Min Max Unit Default ID Description
P3.9.1.2 External fault 0 3 2 701
0 = No action
1 = Alarm
2 = Fault (Stop according to
stop mode)
3 = Fault (Stop by coasting)
P3.9.1.3 InputPhase Fault 0 1 1 730
0= 3 Phases support
1= 1 Phase support
P3.9.1.4 Undervoltage Flt 0 1 0 727
0 = Fault stored in history
1 = Fault not stored in history
P3.9.1.5 OutputPhase Flt 0 3 2 702 See P3.9.1.2
P3.9.1.6 FieldbusComm Flt 0 4 3 733
0 = No action
1 = Alarm
2 = Alarm, PresetFreq
3 = Fault (Stop according to
stop mode)
4 = Fault (Stop by coasting)
P3.9.1.7 SlotComm Flt 0 3 2 734 See P3.9.1.2
P3.9.1.8 Thermistor Fault 0 3 0 732 See P3.9.1.2
P3.9.1.9 PID SoftFill Fault 0 3 2 748 See P3.9.1.2
P3.9.1.10 PID Supervision 0 3 2 749 See P3.9.1.2
P3.9.1.11 ExtPID Supervision 0 3 2 757 See P3.9.1.2
P3.9.1.13 PresetAlarmFreq P3.3.1.1 P3.3.1.2 Hz 25.00 183
This frequency used when
fault response (in Group 3.9:
Protections) is Alarm+preset
frequency
P3.9.1.14 STO Fault 0 3 3 775
Defines drive operation when
STO function has been acti-
vated (eg. Emergency stop
button has been pressed).
Table 71. Supervision settings

Vacon 100X series Specifications

General

Product series	Vacon 100X
Category	Controller
Protection Class	IP66 / Type 4X
Frequency	50/60 Hz
Braking Chopper	Built-in
Ambient Temperature	-10°C to +40°C, up to +50°C with derating
Control Method	Vector control
Input Voltage	525-690V
Communication Options	CANOpen
Mounting	Wall-mounted
EMC Filter	Built-in
Cooling Method	Air-cooled
Protection Features	Overtemperature, Overvoltage, Undervoltage
