Vacon 100X series - Description of the Applications

3
vacon • 9 Startup
3.2 Description of the applications
Use the parameter P1.2 (Application) to make a selection of an application for the drive. Imme-
diately when the parameter P1.2 changes, a group of parameters get their preset values.
3.2.0.1 M1 Quick setup parameter group
In the Quick Setup parameter group you will find the different wizards of the Vacon 100 X Solar
Pump Application. The wizards help you to quickly set up your drive for use prompting you for
a number of essential data.
Table 1. Quick setup parameter group
Code Parameter Min Max Unit Default ID Description
B1.1 Startup wizard 0 1 0 1170
0 = Do not activate
1 = Activate
Choosing Activate initiates
the Startup Wizard (see
chapter 3.1).
P1.2 Application 0 5 0 212
0 = Standard
1 = Local/Remote
2 = Multi-Step Speed
3 = PID Control
4 = Multi-Purpose
5 = Motor
Potentiometer
P1.3 MinFreqReference 0.00 P1.4 Hz 0.00 101
Minimum allowed fre-
quency reference
P1.4 MaxFreqReference P1.3 320.00 Hz 50.00 102
Maximum allowed frequency
reference
P1.5 Accel Time 1 0.1 300.0 s 5.0 103
Defines the time required
for the output frequency to
increase from zero fre-
quency to maximum fre-
quency
P1.6 Decel Time 1 0.1 300.0 s 5.0 104
Defines the time required
for the output frequency to
decrease from maximum
frequency to zero frequency
P1.7 Current limit Varies Varies A Varies 107
Maximum motor current
from AC drive
P1.8 Motor type 0 1 0 650
0 = Induction motor
1 = PM motor
P1.9 Motor Nom Voltg Varies Varies V Varies 110
Find this value U
n
on the
rating plate of the motor.
Note also used connection
(Delta/Star).
P1.10 Motor Nom Freq 8.00 320.00 Hz Varies 111
Find this value f
n
on the rat-
ing plate of the motor.
P1.11 Motor Nom Speed 24 19200 rpm Varies 112
Find this value n
n
on the rat-
ing plate of the motor.
P1.12 Motor Nom Currnt Varies Varies A Varies 113
Find this value I
n
on the rat-
ing plate of the motor.
P1.13 Motor Cos Phi 0.30 1.00 0.74 120
Find this value on the rating
plate of the motor
