Vacon NX User Manual

11
vacon • 192 Non-regenerative front end
Local contacts: http://drives.danfoss.com/danfoss-drives/local-contacts/
Table 87. Digital Output G2.3.1
Code Parameter Min Max Unit Default ID Desciption
P2.3.1.1 Running 0 59 10 1935
Select for digital output signal MC
running
P2.3.1.2 Close MCB 0 59 20 1936
Selection for digital output close
Main circuit breaker
P2.3.1.3 DC Precharge 0 59 21 1937
Selection digital output signal for
DC Precharging signal
P2.3.1.4 Warning 0 59 40 1938
Select for digital output signal mc
warning
P2.3.1.5 Fault 0 59 41 1939
Selection for digital output sigal
mc fault
P2.3.1.6 No Warning 0 59 0 1940 Inverted warning signal
P2.3.1.6 No Fault 0 59 0 1941 Inverted fault signal
Table 88. Analog Output G2.3.2
Code Parameter Min Max Unit Default ID Desciption
P2.3.2.1 DC Voltage 0 59 10 1942
Selection for analog output signal
dc voltage
P2.3.2.2 Current 0 59 0 1943
Selection for analog output signal
for current
Table 89. Protection G2.4
Code Parameter Min Max Unit Default ID Desciption
P2.4.1 CoolFanFaultMode 1 2 1 1945
Cooling Fan Fault Mode
1=Warning + Fault(after delay)
2=Fault
P2.4.2 Fan Fault Delay 0 15 min 5 1946
The delay time after which a
cooling fan fault will generate.
Until the delay time is finished,
only a warning is on.
P2.4.3 MissPhaseFautMod 0 2 2 1947
Miss input phase fault response
mode
0=no action
1=Warning
2=Fault
P2.4.4 MissPhaseFDelay 0.00 60.00 s 1.00 1948 Missing phase signal wait time
P2.4.5 BreakerFaultMode 0 2 2 1949
MCB feedback signal is missing
after settled time
0=No action
1=Warning
2=Fault
P2.4.6 Breaker Ack Time 0.00 10.00 s 1.00 1950 Breaker feedback signal wait time

Vacon NX Specifications

General

Product Type	AC Drive
Control Method	Scalar Control
Enclosure	IP00, IP21
Communication	Ethernet
Safety	STO (Safe Torque Off)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Ambient Temperature Range	-10°C to +50°C (with derating above +40°C)
Cooling Method	Air-cooled, Liquid-cooled
