J. Specifications
---107---
J 10.1.4. Valves for auxiliary hydraulics
As standard one 2/1---acting valve of 3---positions and one 2---acting valve of 4---positions, the float position is locked, as
option two extra valves and a brake valve for trailer can be mounted.
J 11. Other specifications
J 11.1. The capacity of the cab filter
Standard filter (dop test, 300 m
3
) > Ø 0.2 Nm 10 %, > Ø 1 Nm 20 %, > Ø 5 Nm 90 %, > Ø 8 Nm. . . . . . . . . . . . . . . . . . . .
100 %
Active coal filter, cab (dop test, 200 m
3
) > Ø 2 Nm 100 %, from gases > 98 %. . . . . . . . . . . . . .
J 11.2. Code number table for calibrating
The code numbers of the table are used when calibrating the Agroline instrument panel after changing tyres/tires.
Code numbers with different tyre/tire sizes and transmission types
Rear wheel
Code num-
bers
Rear wheel
Code num-
bers
12.4R36 148 18.4---34 136
13.6---36 147 18.4R30 142
13.6---38 140 18.4R34 132
13.6R24 186 18.4R38 124
13.6R36 145 20.8R38 119
13.6R38 140 230/95R48 130
14.9---30 156 340/85R38 140
14.9R38 135 420/85R34 138
16.9---30 151 460/85R34 132
16.9---34 138 480/70R30 147
16.9R30 148 480/70R34 139
16.9R34 138 520/70R34 132
16.9R38 129 540/65R34 137
NOTE: If a tractor has tyres/tires which are not listed in this table, the code number can passably be calculated
as follows:
X =
Y x V
v
max
in which
X= correct code number
Y= actual code number in AL---instrument
V= tractor’s constructional speed (30 or 40 km/h)
V
max
=tractor’s max driving speed which is shown by AL ---instrument
Example:
In AL---instrument there is an actual code number 155. Tractor’s constructional speed is 40 km/h. AL---instrument shows
the tractor max. driving speed of 39 km/h.
X =
155 x 40
39
=
159
