Valtra 900 - D 1.5. Controls on Left Hand Side

---25---
D. Instruments and controls
Place for the fastening rack
100 mm
100 mm
Ø10 mm
69---12,3
In the centre pillar on the RH side under the covering
panel there are two fastening holes with M8 threads.
These fastening points are located below the covering
panel middle screw in the same line with the panel fixing
screws and are 100 mm from each others. To make the
fastening holes accessible, carefully drill 10 mm holes at
exactly the above mentioned points.
D 1.5. Controls on left hand side
65---13
1
2
3
For more detail see page 44.
1 Parking brake
2 Engaging control, four---wheel drive
3 Extra seat
