K. Extra equipment
K 2.3.2. HiShift for the rear PTO switch
1. Instructions for operating
69---130
1
2
3
The rear PTO HiShift switch (1) is situated on the right
side panel or side pillar, depending on the equipment.
With the HiShift switch (1) of the rear PTO, the PTO can be
switched on and off without using the PTO (2) clutch lever.
The disengagement with the clutch lever (2) is always
possible.
NOTE: With the HiShift switch (1) or the lever the PTO
can be disengaged only temporarily (max. 5 min.).
When the PTO has been disengaged with this lever the
indicator light the instrument panel lights up on.
The switch is a three position switch:
--- When the opposite side to the symbols is pressed
down = OFF, PTO disconnected
--- In the centre position = ON, PTO connected (fast en-
gagement)
--- When the symbols side is pressed down, spring loa-
ded = slow engagement of the PTO
The engagement and disengagement of the PTO will be
done the same way, when using the HiShift (1) or the
clutch lever (2).
1.1. Engagement
--- Adjust the engine speed to low idling
--- Press the opposite side to the symbols of the HiShift (1)
down to disconnect the clutch disc = OFF---position,
the light on the instrumentpanel is on
--- Move the PTO selector lever (3) to the desired PTO ran-
ge speed position
Fast engagement
--- If the rotating material/mass of the implement engaged
with the PTO, is small, the PTO will be engaged by pres-
sing the HiShift (1) in the middle position (ON). In that
case the PTO starts to rotate quickly.
Slow engagement
--- If the load is greater, press the symbol side of the HiShift
(1) down and hold until the PTO is totally connected.
After that the switch will be released.
1.2. Disengagement
Adjust the engine speed to low idling
--- Press the opposite side of the symbols of the HiShift (1)
down to detach the clutch disc = OFF---position, the
light on the instrument panel is on.
--- Move the PTO selector lever (3) to the middle position
= the PTO range speed is off.
--- Press the PTO HiShift switch (1) to the middle position
NOTE: The PTO HiShift switch (1) must always be in mid-
dle position (= the light on the instrument panel is off),
if the PTO is not in use.
For more details on using the PTO see the Working in-
structions beginning (in section F) on page 52.
