Valtra 900 - H 3. Maintenance weekly (at least every 50 hours)

---69---
H. Periodic maintenance
H 3. Maintenance weekly (at least every 50 hours)
H 3.1. Lubricate the front axle and
steering nipples (3)
Use Valtra Universal Grease.
2---wheel drive models
A3565---87
A
B
B
A
A. Front axle mountings: Lubricate the nipples (two) with
grease (lift up the front end to take the weight off the
axle).
B. Steering knuckles: Turn the steering wheel backwards
and forwards when lubricating (2 pcs).
4---wheel drive models
A3565---88,1
A
A
A. Front axle mountings: Lubricate the nipples with grease
(lift the front end to take the weight off the axle), 2 pcs.
H 3.2. Lubricate the brake and clutch
pedals (4)
65---89
Use Valtra Universal Grease.
One nipple on left side for lubricating the clutch pedal
bearing and two nipples on right side for lubricating the
brake pedal bearings.
