---117---
K. Extra equipment
--- push the axle forward, and into the sleeve
--- thread the belts away from the opening
--- if the opening is too small, the fastening screws of the
machinery have to be loosened and the machinery
pulled forward, until the opening is large enough
--- mount in the reverse order: tighten the screws to torque
of 200 Nm (4 pcs). Tighten the flange screws (1) to 90
Nm.
2.3. Maintenance every 500 hours
1.
Change oil every 500 hours (after every half year).
3
4
69---121
5
--- The oil is drained through drain hole 3. The housing is
filled with 10W30 oil (1,4 litres) to the level at inspection
hole 4. Breather 5 can be loosened for bleeding. Check
that the breather is not blocked. When filling the tractor
has to be levell.
Oil quality 10W/30, API CE/SF, API GL 5/4, CCMC D4.
2. Check the condition of the rubber joint (2) after 500
hours use, check it has no wears/breaks/leaks. Change
when needed:
--- Spread a little Valtra Universal Grease to the under
surfaces of the attaching screws before fastening.
--- Tighten the screws to 140 Nm so that the rubber will not
twist (three screws of axial direction and three of circular
direction).
3.
Specifications
--- Controlled by the switch in the instrument panel
--- The nominal speed is 1000 r/min with the engine speed
at 2120 r/min
--- Driving speeds of front PTO nominal revs with different
gears are 2 % greater than corresponding speeds at
rear PTO (1000 r/min), see page 103.
--- 6---splines shaft, Ø 35 mm
--- Electrohydraulically controlled, wet multidisc clutch
--- Pre---programmed/programed soft starting
--- Rotating direction anticlockwise seen from front.
