---108---
J. Specifications
J 12. Wiring diagram, component list (Wiring diagram on pages 110---112)
Component list number 33202100 L
Optional or alternative equipment listed in brackets
Sym--- Code
bol Component no
A1 Current screw, cabin supply 1
(A2) Radio 38
(A3) Controller, front PTO 22
(A5) Air suspension seat 32
B1 Sensor, engine temperature gauge 8, 59
B2 Sensor, fuel gauge 9
(B3) Sensor, gearbox temperature* 49
(B6) Sensor, gearbox* 47
E1 Headlight, right 30
E2 Headlight, left 29
E3 Front direction indicator, right 36
E4 Front direction indicator, left 35
E5 Rear light, right 37
E6 Rear light, left 34
E7 Cab light 18
E8 Thermostart 4
E9 Rear working light, right 25
E10 Rear working light, left 25
(E11)Front working light, right 26
(E12)Front working light, left 26
E13 Instrumentation lights 8, 10
(E15)Cigarette lighter 16
(E16)Number plate light 34
(E17)Raised headlights, right 28
(E18)Raised headlight, left 27
(E19)Fog light, rear 52
(E22)Lights on roof console 57
FA, FB, FC, FD Fuses
FA1 5A Instruments, ind.lights, Autocontrol, fuel
gauge 9, 44
FA2 10A Rot. warning light, radio 24
FA3 15A Wiper+washer, rear wiper+washer 12
FA4 5A Front PTO, light switch illum. light, current
socket 28
FA5 15A Direction indicators, braking lights, reverse
buzzer, air suspen. seat, warning flashers 38, 58
FB1 25A Light switch 29
FB2 15A Dipped beams 29
FB3 15A Full beams, ---indication light 29
FB4 5A Autocontrol 43
FB5 20A Starter switch, electric---stop,
rear fog light, control stop, Thermostart 3, 52, 60
FC1 10A Cigarette lighter, cab light 17
FC2 15A Rear working lights 25
FC3 15A Horn, rear socket, front working lights, hazard
warning flashers 40
FC4 5A Left parking light, instrumentation lights,
working light switches, hazard warning flashers illum.
light 35
FC5 Parking light, right 36
FD1 20A Fan, upper fan I---II-speed, Air---conditioner 12
FD2 20A Air---conditioner, upper fan III-speed 56
FD3 10A HiShift, PTO---HiShift, radio 62---63
FD4 25A Current socket 64
FD5 5A Radio, (clock*), light alarm buzzer 1
In engine room
(F51) 15A Electrically controlled main circuit breaker 70
Sym--- Code
bol Component no
G1 Battery 1
G2 Alternator 3
H1 Indicator light, direction indicators II 40
H2 Indicator light, direction indicators I 39
H4 Indicator light, air filter 6
H5 Indicator light, engine oil pressure 7
H6 Warning light, Stop, engine temperature 7, 59
(H7) Indicator light, gearbox oil pressure
H11 Indicator light, parking brake 9
(H12)Indicator light, Thermostart 5
H13 Indicator light, PTO clutch 6
H14 Indicator light, high beams 31
H15 Indicator light, fuel reverse 9
H16 Indicator light, charging 4, 68
H20 Indicator light, differential lock 5
H23 Horn 40
(H24)Rotating light 24
(H27)Rear buzzer 58
H30 Light alarm buzzer 47
H31 Direction indicator, left 39
H32 Direction indicator, right 35
K1 Auxiliary relay, starter (ignition switch) 2
K2 Direction indicator relay 39
(K3) Relay, front working lights 26
K4 Relay, rear working lights 26
K5 Headlight dipper switch relay 29
K6 Auxiliary relay, starter switch 5
(K7) Relay, rear fog light 52
(K8) Relay, roof fan III---speed 56
K9 Auxiliary relay, starter switch 6
(K18)Relay, control stop 60
(K24)Reley, HiShift 63
(K25)Relay, PTO---HiShift 65
(K51)Relay, indicator light, contr. main current switch 69
M1 Starter motor 2
M2 Heater fan 12
M3 Windscreen wiper 15
M4 Windscreen washer pump 14
(M5) Roof fan 55
(M6) Rear window wiper 20
(M7) Rear window washer 19
P1 Engine temperature gauge 8
P2 Fuel gauge 9
P3 Rev counter 10
P4 Hour recorder/AC (.../speed*) 11
(P5) Clock, AC, trip, gearbox oil temperature* 47
(Q2) Main circuit breaker 1
R1 Resistance, heating fan 1,2 ohm 12
S1 Ignition switch 2, 60
(S2) Switch, roof fan 55
(S3) Switch, rear window wiper and washer 18
S4 Switch, windscreen wiper and washer 15
S5 Switch, heater fan 13
(S6) Switch, rotating warning light 23
S7 Switch, headlights 29
S8 Switch, rear working lights 25
(S9) Switch, front working lights 27
S10 Combined switch 32
(S11)Toggle switch, raised headlights 29
S12 Contact, starter interlock 2
S13 Brake light contact 35
