J. Specifications
Wiring diagram, component list (Wiring diagram on pages 110---112)
Sym--- Code
bol Component no
S14 PTO warning light contact 6
S15 Indicator light switch, engine oil press. 7
S16 Switch, hazard warning flashers 36
S17 Indicator light switch, diff. lock 6
S18 Indicator light switch, hand brake contact 10
(S19)Contact, reverse buzzer 58
S20 Indicator light switch, engine temperature,
(Stop) 8, 59
S21 Indicator light switch, air cleaner 6
(S22)Switch, air conditioning 54
(S23)Switch, compressor pressure 54
(S26)Switch, rear fog light 51
(S36)Switch, control stop 61
(S37)Switch, cursor+program* 47
(S38)Contact, front PTO 22
S42 Door switch, cab light, right 18
S43 Door switch, cab light, left 18
(S45)Switches, HiShift 62---63
(S45.1)Extra switch, HiShift 62
(S68)Switch, controlled main current switch 70
(S69)Switch, PTO---HiShift 69
(V5)Diodes, HiShift 62---63
(V6)Diodes, PTO---HiShift 65---66
Connectors
X1 37---pins, engine
X2 9---pins, head lights 29---30
X4 7---pins, trailer socket 37, 53
X4.1 3---pins, trailer socket 37, 53
X4.2 3---pins, trailer socket 37, 53
X5 9---pins, mudguard right
X6 9---pins, mudquard left
(X7) 4---pins, air condition
(X8) 2---pins, current socket 38
(X9) 1---pins, rear wiper 17
(X15) 3---pins, air conditioning, diodes 54
X20 9---pins, front direction indicators
(X22) 2---pins, rotating light
X25 9---pins, Agrodata---instrumentation
X26 26---pins, instrumentation, white
X27 26---pins, instrumentation, blue
(X42) 4---pins., front---PTO supply 22
(X44) 1---pin, control stop, optional equipment 59
(X49) 2---pins, air suspension seat 32
X50 3---pin, current socket 64
X51 1---pin, rear buzzer
Y1 Solenoid valve, electric stop 5, 60
(Y5) Magnetic clutch, compressor, air condition 54
(Y9) Solenoid valve, front PTO 22
(Y14) Solenoid valve, HiShift 62
(Y15) Solenoid valve, HiShift, retardation 63
(Y16) Solenoid valve, PTO---HiShift 65
(Y17) Solenoid valve, PTO---HiShift, retardation 66
Ground leads
GR1 Battery
GR2 Headlights (starter)
GR3 Instrument panel
GR4 Earth lead, rear right
GR5 Cabin roof
GR6 Cabin front wall
*) AL---instrumentation 47---49
Sym--- Code
bol Component no
ACB Autocontrol power lift
A1E Autocontrol electronic unit 42---44
A2E Switch panel 45
B1E Position sensor 41
B2E Draft sensor 41
E1E Lightning, switch panel 45
E2E Lightning, position control potentiometer 46
R1E Potentiometer, position control 45
S1E Push button, RH mudguard, lifting 43
S2E Push button, RH mudguard, lowering 43
S3E Push button, LH mudguard, lifting 42
S4E Push button, LH mudguard, lowering 42
S5E Push button, lift/lower, inside 44
S7E Switch, lowering speed 45
S8E Switch, transport height 45
S9E Switch, position/draft control sensitivity 45
S10E Rocker switch, lift/stop/lower 45---46
S11E Switch, AC---bypass 44---45
S12E Switch, drive balance control 45
X2E Connector, 9 pins, supply+rear drive switch 42
Y1E Solenoid valve, lowering 41
Y2E Solenoid valve, lifting 41
Wire colours
VA = white
HA = grey
KE = yellow
VI = green
SI = blue
LI = lilac
PU = red
RU = brown
MU = black
