K. Extra equipment
hitch
Hydraulic trailer hitch + agricultural towing device
Wagon towing device frame
Towing coupling D (fixed bolt Ø 31,5 mm)
Towing coupling A10 (fixed bolt Ø 31
mm)
Towing coupling A11 (fixed bolt Ø 38
mm)
Towing coupling C (demountable pin Ø
28 mm, Italy)
Towing coupling D2 (demountable pin Ø
43 mm, Italy)
Towing coupling D3 (demountable pin Ø
50 mm, Italy)
Wagon towing device frame + fixed hitch
(Piton Fix) + agricultural towing device
Long fra-
me,
width 330
mm
Hydraulic trailer hitch + wagon towing
device frame
Hydraulic trailer hitch+ agricultural towing
device + wagon towing device frame
Agricultural towing device (fixed) without
hydraulic trailer hitch + wagon towing
device frame
Agricultural towing device (fixed) without
hydraulic trailer hitch North America +
wagon towing device frame
Hydraulic trailer hitch + agricultural towing
device (fixed) without hydraulic trailer hitch
North America + wagon towing device
frame
Towing coupling D (fixed pin Ø 31,5 mm)
Short fra-
me,
width 295
mm
Agricultural towing device North America
Hydraulic trailer hitch + agricultural towing device North
America
K 1.8.2.
Extra valve blocks
When ordering the extra valve blocks you have to know if
it is third or fourth valve block:
Auxiliary hydraulic valve block double---acting:
push---hold---pull, included DA---SA convertor (allows
2/1 valve block acting)
Auxiliary hydraulic valve block double---acting:
push---float---pull, position locked
Auxiliary hydraulic valve block double---acting:
push---hold---pull---float, float locked
Auxiliary hydraulic valve block double---acting:
push---hold---pull, position locked
Change valve (in order, the valve block has to select
(mounting))
K 1.8.3.
Three point linkage, equipment
Lift link ram, hydraulic
Top link hydraulic
Top link, long ball---hitch (Cat 2)
Lowering links, telescopic (980 mm) + top link long
Lower link, ball---hitch (Cat 2) (980 mm)
Extra cylinder, power lift (600, 700)
K 1.8.4.
Front linkage
Front linkage, (including the third valve), on 2WD models
max load 1000 kg
Front weight bracket for front linkage (three point linkage)
Cat 2
K 1.8.5.
Other
Bio oil (only in hydraulics)
K 2. Extra equipment, operating and service
In this section provides the operating and service
instructions of the more complicated extra equipment,
which need special attention.
