---116---
K. Extra equipment
K 2.3. Power transmission
K 2.3.1. Front power take---off
1. Instructions for operating
1
2
4 x 200 Nm
69---118,1
A front PTO is only available with front linkage.
When using the front PTO read the instructions for the rear
PTO.
The front PTO switch (1) is situated on the right side panel
(on the models with mechanical lift the switch is located
on the side pillar). The switch is a two position rocker
switch.
--- Right side pressed down: front PTO is on.
--- Left side pressed down: front PTO is off.
Front PTO shaft (2) diameter is 35 mm and it is 6---spline.
69---114
CAUTION: The front PTO shaft nominal rotating speed
is 1000 r/min and the rotating direction is to the left
viewed from front. Check that the implement is
compatible before connecting.
The front PTO shaft nominal revs of 1000 r/min
corresponds to the engine revs of 2120 r/min.
The front PTO engagement is cushioned by precontrolled
electric. If the connection is very slow or very fast, then the
electric adjustment may be adjusted which should be
carried out by the authorized workshop.
2.
Maintenance
2.1. General
1. Tighten the screws of the PTO after the first 15---25
running hours. Regularly check the torque of the fixing
bolts and hydraulic system. Contact the authorized
workshop, if any leaks occur.
2.2. Changing belts
1
2
69---119
--- loosen the screws of the flange (1)
