---76---
H. Periodic maintenance
H 5.8. Change pressure filter in hydraulic
system (23)
A3565---100
--- Clean surrounding parts
--- Loosen the filter and take out the element
--- Wash the filter housing with diesel fuel and fit the new
element (oil the seal first). The seal must always be
changed.
--- Tighten the filter with a suitable wrench to a torque of
200 Nm.
NOTE: Always change the filter when carrying out
repairs caused by impurities in the hydraulic system.
Clean suction strainer as described earlier (see service at
1000 hours intervals page 78).
CAUTION: If the external hydraulics are used
extensively and no return oil filter is used, the filter
must be changed ever 250 hours.
If the external hydraulics are used extensively it is
recommended that a return filter should be mounted in
the line (extra equipment).
On tractors with a return filter, all oil which is returning
from the outside machine, goes through the return filter.
Follow to changing intermediate on the return filter.
H 5.9. Change oil filter in
transmission (24)
65---77
--- Clean surrounding parts and remove the filter
--- Oil a new seal and fit the new filter. Tighten by hand (not
too tight).
H 6. Maintenance every 1000 hours (or yearly)
H 6.1. Change oil and oil breather filter in
hydraulic system (25)
Draining
65---78
--- Run the tractor for warm up the hydraulic oil.
--- Remove the drain plug and drain off the oil
--- Clean the plug and replace it in again
Refilling
69---79,1
1
2
3
4
--- For refilling the oil, first open the breather filter (2)
together with the fastening tube (3) by opening the
locking nut (4) (hole inside the breathers fastening tube
is too small for refilling the oil).
--- Refill with new oil through the filling cap. The lower mark
on the dipstick (1) corresponds to 25 l, the upper mark
to 35 l. The system may be filled to any level between
these two points.
