---47---
D. Instruments and controls
ploughing/plowing).
D 2.8.2. Lock for adjustment for
forwards/rearwards (2)
Lift up the lever and push the seat forwards or rearwards.
D 2.8.3. Seat suspension control (3)
Turn the control clockwise to make the suspension harder.
The decal (3A) shows recommended settings for different
driver weights.
D 2.8.4. Seat belt anchor point (4)
There are anchor points for the seat belt on the seat.
D 2.8.5. Seat back inclination (5)
Pull this lever up then set the back rest to the desired
position.
D 2.8.6. Vertical adjustment (of seat) (6)
Raising: Lift the seat to the desired position. The seat will
automatically lock in position.
Lowering: To lower the seat you have to first lift the seat
to the top position and allow it to drop to the bottom
position. You must then lift it up to the desired position.
Air suspension ---driver’s seat see page 124.
