---80---
H. Periodic maintenance
H 6.10. Check and adjust toe---in of front
wheels (34)
A
A+ 2...6 mm
(4---WD:A+0...2 mm)
3565---118
See under ”Checks and Adjustments” on page 91.
H 6.11. Check and adjust valve clearance
(35)
A3565---120
Both inlet and exhaust valves should have a valve
clearance of 0.35 mm (0.014 in). The valve clearance can
be adjusted when the engine is either warm or cold.
Checking and adjustment should be carried out by an
authorized workshop.
H 6.12. Change cab air filter and upper
filter
(extra equipment) (36)
Change lower filter
69---66,2
Lift up the filter housing cover (rear part first) and replace
the filter with a new one. Change filter more often if
necessary.
Change upper filter (extra equipment)
69---66
Remove air cleaner housing from the front part of the roof
and replace the filter with a new one. Change filter more
often if necessary.
