Vertiv | NetSure™ 8200 Series -48 VDC Power System Installation Manual (IM582140000) | Rev. A
Installation Procedure for P/N 514690 and 514691
DANGER! Before performing this procedure, ensure that the power/distribution bay is COMPLETELY
DISCONNECTED from all power sources.
NOTE! Apply electrical anti-oxidation compound to mating surfaces of busbars before connecting
together.
1. Assemble the busbar kit to the top of the bays as shown in Figure 40 through Figure 45. Refer to
Figure 44 and Figure 45 for assembled views. Note that these busbar kits require "External Top-Mount
Horizontal Battery Input Busbar Assembly", P/N 554873. These busbar kits attach to the P/N 554873
busbar kit.
