Vertiv | SmartCabinet | User Manual 13
System Installation
Name Drawing Name Drawing
Insulated torque wrench
Torque screwdriver
Multimeter
Clip-on ammeter
Utility Knife
Gradienter
Allen key
Apart from this, another accessory that is quite useful in the pre-installation and installation procedures, is the
Floating nut hook.
The appearance of the oating nut hook is shown in Figure 2-1.
Figure 2-1 Floating nut hook
The oating nut hook is used to install the oating nut.
Following are the steps to be followed for the installation of the oating nut:
1. Insert one fastener of the oating nut into the square hole of the vertical mounting rails, as shown in Figure
2-2.
