Victory 2009 VISION User Manual

154
MAINTENANCE
Maintenance
Rear Suspension Adjustment (Cont.)
Adjustment Procedure
1. Open left saddlebag door.
2. Remove cap from air fitting (1) in left bag.
3. Read recommended air pressure from decal for
total cargo and occupant weight. Use the
appropriate column (with trunk or no trunk).
4. Screw hose fitting of PV-48909 securely onto air
fitting and read air pressure on gauge.
5. To REDUCE air pressure, push the bleed button (2)
located on side of gauge. Bleed pressure in small
amounts until desired pressure is indicated on gauge. Remove the tool hose from air
fitting and install the cap.
6. To INCREASE pressure, install the gauge select the desired pressure from the chart
as described in steps 1-4 above. Pump the handle (3) until pressure increases to the
desired amount, then remove the hose and install the cap.
DO NOT exceed 72 PSI (496 kPa) in the shock.
1
2
3
8maintenance.fm Page 154 Wednesday, April 16, 2008 2:05 PM

Victory 2009 VISION Specifications

General

Year	2009
Manufacturer	Victory
Model	VISION
Category	Touring
Compression Ratio	9.4:1
Cooling System	Air / oil
Transmission	6-speed
Final Drive	Belt
Front Tire	130/70-R18
Rear Tire	180/60-R16
Engine Type	V-twin, four-stroke
Displacement	1731 cc
Bore x Stroke	101 x 108 mm
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Rear Suspension	Single
Front Brakes	Dual 300mm discs, 4-piston calipers
Rear Brakes	Single 300mm disc 2 piston caliper
Seat Height	26.5 inches
Fuel Capacity	22.7 liters / 6.0 US gallons
Wheelbase	65.7 inches
