Victory 2009 VISION User Manual

183
MAINTENANCE
Maintenance
Battery Installation
1. Slide the battery into the battery box. Be sure tabs
(1) at the bottom are engaged with slots (2) on
inner battery box.
NOTE:
Replace damaged or missing foam pads.
2. Install battery into box with terminals facing
forward. Tip the front battery box with battery
toward battery box and install bolt (3). Torque bolt
to specification.
3. Install positive battery cable first.Torque battery terminal bolt to specification.
4. Install red protective boot over positive (+) terminal. Install negative cable. Torque bolt
to specification.
5. Connect grill halves and install scoop (page 181).
CAUTION
Connecting the negative cable first can produce an
electric shock that could result in damage or injury.
Always connect the positive cable first.
+ Terminal
- Terminal
Forward
2
1
36 lb-in. (4 Nm)
85 lb-in. (10 Nm)
3
visionownersmanual.book Page 183 Wednesday, February 13, 2008 4:31 PM

Victory 2009 VISION Specifications

General

Year	2009
Manufacturer	Victory
Model	VISION
Category	Touring
Compression Ratio	9.4:1
Cooling System	Air / oil
Transmission	6-speed
Final Drive	Belt
Front Tire	130/70-R18
Rear Tire	180/60-R16
Engine Type	V-twin, four-stroke
Displacement	1731 cc
Bore x Stroke	101 x 108 mm
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Rear Suspension	Single
Front Brakes	Dual 300mm discs, 4-piston calipers
Rear Brakes	Single 300mm disc 2 piston caliper
Seat Height	26.5 inches
Fuel Capacity	22.7 liters / 6.0 US gallons
Wheelbase	65.7 inches
