Victory 2009 VISION User Manual

182
MAINTENANCE
Maintenance
Battery Removal (Cont.)
4. Remove the negative (-) battery cable from
battery terminal (3) with a 10mm wrench.
5. Lift the red protective boot (4) off of the positive
(+) cable end to expose positive terminal.
Remove the positive cable from the battery
terminal (10 mm wrench).
6. Remove the front battery box bolt (5) with a
10mm socket.
7. Tip the front box forward and lift the battery up to
clear the case and then out the bottom side.
3
4
5
Viewed from right front side
visionownersmanual.book Page 182 Wednesday, February 13, 2008 4:31 PM

Victory 2009 VISION Specifications

General

Year	2009
Manufacturer	Victory
Model	VISION
Category	Touring
Compression Ratio	9.4:1
Cooling System	Air / oil
Transmission	6-speed
Final Drive	Belt
Front Tire	130/70-R18
Rear Tire	180/60-R16
Engine Type	V-twin, four-stroke
Displacement	1731 cc
Bore x Stroke	101 x 108 mm
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Rear Suspension	Single
Front Brakes	Dual 300mm discs, 4-piston calipers
Rear Brakes	Single 300mm disc 2 piston caliper
Seat Height	26.5 inches
Fuel Capacity	22.7 liters / 6.0 US gallons
Wheelbase	65.7 inches
