Victory 2009 VISION User Manual

96
PRE-RIDE CHECKS
Pre-Ride
Check Brake Pads
Look at each front brake pad on both sides of
the front disc at viewing angle (1).
Look at each rear brake pad on both sides of
the rear disc at viewing angle shown (2).
You should see at least 1.5 mm of friction
material
on each front brake pad, and a
minimum of 1.0 mm of friction material on each
rear brake pad. If in doubt, measure remaining
friction material.
See page 172 for brake disc inspection.
Check each caliper for dampness or stains
from leaking or dried fluid that would indicate a
leak from caliper piston seals (behind the
brake pads), a brake hose, or a connection.
Have your VICTORY dealer replace brake
pads if worn beyond the minimum friction
material thickness at their thinnest point, or if
brake fluid leakage is evident. (See WARNING: page 95.)
Example of
friction material
thickness
Friction material
1
2
Minimum:
Front Pad
(1.5 mm)
Minimum:
Rear Pad
(1.0 mm)
visionownersmanual.book Page 96 Wednesday, February 13, 2008 4:31 PM

Victory 2009 VISION Specifications

General

Year	2009
Manufacturer	Victory
Model	VISION
Category	Touring
Compression Ratio	9.4:1
Cooling System	Air / oil
Transmission	6-speed
Final Drive	Belt
Front Tire	130/70-R18
Rear Tire	180/60-R16
Engine Type	V-twin, four-stroke
Displacement	1731 cc
Bore x Stroke	101 x 108 mm
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Rear Suspension	Single
Front Brakes	Dual 300mm discs, 4-piston calipers
Rear Brakes	Single 300mm disc 2 piston caliper
Seat Height	26.5 inches
Fuel Capacity	22.7 liters / 6.0 US gallons
Wheelbase	65.7 inches
