Victory 2009 VISION User Manual

195
MAINTENANCE
Maintenance
Headlamp Bulb Replacement
To replace a headlamp bulb:
1. Remove air filter (page 143). Pull sealing boot
away from the back of the bulb(s) and housing.
2. Press the looped end of the wire clip bulb retainer
and swing the end toward the center of the bulb to
release it from the latch tab.
3. Pull bulb out with wire connector attached.
4. Disconnect wire harness. Install new bulb. DO
NOT TOUCH glass portion of headlamp bulb. Oil
on the glass surface of bulb could cause bulb
failure. Clean with denatured alcohol if touched.
5. Install bulb by reversing steps. Be sure boot is
sealed tightly around bulb base and lens to
prevent moisture from forming inside the lamp.
Headlamp
Bulb Access
visionownersmanual.book Page 195 Wednesday, February 13, 2008 4:31 PM

Victory 2009 VISION Specifications

General

Year	2009
Manufacturer	Victory
Model	VISION
Category	Touring
Compression Ratio	9.4:1
Cooling System	Air / oil
Transmission	6-speed
Final Drive	Belt
Front Tire	130/70-R18
Rear Tire	180/60-R16
Engine Type	V-twin, four-stroke
Displacement	1731 cc
Bore x Stroke	101 x 108 mm
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Rear Suspension	Single
Front Brakes	Dual 300mm discs, 4-piston calipers
Rear Brakes	Single 300mm disc 2 piston caliper
Seat Height	26.5 inches
Fuel Capacity	22.7 liters / 6.0 US gallons
Wheelbase	65.7 inches
