Victory 2009 VISION User Manual

198
MAINTENANCE
Maintenance
Electrical Precautions
Be aware of the following DO’s and DON’Ts regarding the electrical system, in order to
avoid disruption of electrical signals and possible system malfunction.
DO’s
• DO use ONLY genuine VICTORY parts and accessories designed for your model and
follow the instructions provided.
• DO use the accessory power jack provided in the glove compartment or in the trunk
(Tour model). The glove compartment Accessory Power power jack is powered
whenever the ignition key is in the ON or ACC position. The trunk Accessory Power
jack is powered at all times.
• If it is necessary to provide power to an item that does not use one of the previously
mentioned power supply jacks, connect to the load side of the main circuit breaker
(located under the cover behind the oil cooler) and connect the ground wire to the
engine ground at the front left side of the crankcase (near the circuit breaker).
(Continued on next page)
visionownersmanual.book Page 198 Wednesday, February 13, 2008 4:31 PM

Victory 2009 VISION Specifications

General

Year	2009
Manufacturer	Victory
Model	VISION
Category	Touring
Compression Ratio	9.4:1
Cooling System	Air / oil
Transmission	6-speed
Final Drive	Belt
Front Tire	130/70-R18
Rear Tire	180/60-R16
Engine Type	V-twin, four-stroke
Displacement	1731 cc
Bore x Stroke	101 x 108 mm
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Rear Suspension	Single
Front Brakes	Dual 300mm discs, 4-piston calipers
Rear Brakes	Single 300mm disc 2 piston caliper
Seat Height	26.5 inches
Fuel Capacity	22.7 liters / 6.0 US gallons
Wheelbase	65.7 inches
