Victory 2009 VISION User Manual

196
MAINTENANCE
Maintenance
Turn Signal Bulb Replacement (Front)
To replace a front turn signal bulb:
1. Remove the windshield trim panel (page 184).
2. IMPORTANT: Disconnect the wire harness from
socket BEFORE removing socket from the lens.
Lift the lock tab on the connector and push
connector off of the socket.
3. Rotate the bulb socket counter-clockwise 1/4
turn and remove the socket with bulb.
4. Pull out the old bulb and install the new.
5. Install the socket by engaging in the socket
holder and rotating 1/4 turn clockwise.
6. Connect the wire harness. Be sure it snaps
securely into place over the connector lock tab.
NOTE:
Running light (innermost bulb) replacement is the
same as the turn signal bulb, with one exception:
leave wire harness attached to bulb socket when
removing socket from lens.
Remove harness connector from bulb
socket BEFORE rotating socket to remove
IMPORTANT!
it from the lens.
visionownersmanual.book Page 196 Wednesday, February 13, 2008 4:31 PM

Victory 2009 VISION Specifications

General

Year	2009
Manufacturer	Victory
Model	VISION
Category	Touring
Compression Ratio	9.4:1
Cooling System	Air / oil
Transmission	6-speed
Final Drive	Belt
Front Tire	130/70-R18
Rear Tire	180/60-R16
Engine Type	V-twin, four-stroke
Displacement	1731 cc
Bore x Stroke	101 x 108 mm
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Rear Suspension	Single
Front Brakes	Dual 300mm discs, 4-piston calipers
Rear Brakes	Single 300mm disc 2 piston caliper
Seat Height	26.5 inches
Fuel Capacity	22.7 liters / 6.0 US gallons
Wheelbase	65.7 inches
