Victory 2009 VISION User Manual

192
MAINTENANCE
Maintenance
Trunk Removal (Cont.)
4. Open the trunk and remove all contents.
5. Remove the compartment cover by squeezing
between the notches (1) and lift the cover away.
6. Remove three of the four trunk mount bolts (2) using
a 13 mm socket and an extension on a suitable drive
handle.
7. Support the trunk and remove the last bolt.
8. Install the trim panel as outlined on
page 194.
Trunk Installation
1. Remove street trim panel (page 193) then reverse
steps above.
2. Torque trunk mounting bolts to 26 lb-ft. (35 Nm) and
license plate bracket screws to 36 lb-in. (4 Nm).
1
2
visionownersmanual.book Page 192 Wednesday, February 13, 2008 4:31 PM

Victory 2009 VISION Specifications

General

Year	2009
Manufacturer	Victory
Model	VISION
Category	Touring
Compression Ratio	9.4:1
Cooling System	Air / oil
Transmission	6-speed
Final Drive	Belt
Front Tire	130/70-R18
Rear Tire	180/60-R16
Engine Type	V-twin, four-stroke
Displacement	1731 cc
Bore x Stroke	101 x 108 mm
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Rear Suspension	Single
Front Brakes	Dual 300mm discs, 4-piston calipers
Rear Brakes	Single 300mm disc 2 piston caliper
Seat Height	26.5 inches
Fuel Capacity	22.7 liters / 6.0 US gallons
Wheelbase	65.7 inches
