MAINTENANCE
Maintenance
Rear Suspension Adjustment
To provide the most comfortable ride and proper
ground clearance, adjust air pressure in the rear shock
absorber as specified on the decal (located in left
saddlebag area) for total cargo and occupant weight.
Follow these guidelines to adjust air pressure:
• Rest motorcycle on sidestand on level ground.
Remove all riders and cargo.
• VICTORY Air Pump & Gauge PV-48909 is
preferred for checking and adjusting pressure. If
not available, use a pressurized air source
(maximum line pressure 72 PSI) and the gauge
provided in the tool kit. DO NOT exceed 72 PSI (496 kPa) in the shock.
• Use ONLY A DRY AIR SOURCE, such as a system with a water separator or air line
dryer to prevent moisture from entering the shock. The shock has small volume. Air
pressure increases VERY quickly when using pressurized air.
NOTE:
Each time pressure is checked with the gauge in the tool kit, approximately 4 PSI (27.5 kPa)
is lost to fill the volume of the gauge. Once you’ve set the pressure with the gauge, remove
it quickly to minimize leakage, and expect to see a reduction from the previous reading of
about 4 PSI if you recheck the pressure with the tool kit gauge.
Refer To Decal
On
Motorcycle
MAX PRESSURE:
72 PSI (496 kPA)
8maintenance.fm Page 153 Wednesday, April 16, 2008 2:09 PM

Victory 2009 VISION Specifications

General

Year	2009
Manufacturer	Victory
Model	VISION
Category	Touring
Compression Ratio	9.4:1
Cooling System	Air / oil
Transmission	6-speed
Final Drive	Belt
Front Tire	130/70-R18
Rear Tire	180/60-R16
Engine Type	V-twin, four-stroke
Displacement	1731 cc
Bore x Stroke	101 x 108 mm
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Rear Suspension	Single
Front Brakes	Dual 300mm discs, 4-piston calipers
Rear Brakes	Single 300mm disc 2 piston caliper
Seat Height	26.5 inches
Fuel Capacity	22.7 liters / 6.0 US gallons
Wheelbase	65.7 inches
