43
IDENTIFICATION
I.D.
Component Location - Front View
Front View
1. Front Turn Signal (outer light, each side)
2. Wind Deflector (one each side)
3. Headlamp (high beam)
4. Headlamp (low beam)
5. Driving Lamp (or HID lamp if equipped)
6. Air Filter (front of frame)
7. Tiedown Loop (on frame)
8. Rear Brake Fluid Reservoir
9. Battery
10. Oil Cooler
11. Horn
12. Evaporative Emissions Canister
13. Fuel Tank (one each side)
14. Running Light (inner light, each side)
3
9
2
1
5
6
10
11
12
14
8
7
4
13
