Victory 2009 VISION User Manual

76
INSTRUMENTS, FEATURES, & CONTROLS
Controls
Manual Windshield Adjustment
If your motorcycle is not equipped with a motorized
windshield, you can adjust it manually using the following
procedure:
1. Stop the motorcycle and turn the key OFF.
2. Remove the windshield trim panel (see page 184).
3. Remove the retaining clip (1).
4. Hold slight downward pressure on the bottom of the
windshield (it is under slight upward spring pressure).
5. Remove the clevis pin (2), slide the windshield inner
bracket to align with one of the optional holes in the
outer bracket, then reinstall the clevis pin.
6. Install the retaining clip in the clevis pin.
7. Install the windshield trim panel (page 184).
1
2
visionownersmanual.book Page 76 Wednesday, February 13, 2008 4:31 PM

Victory 2009 VISION Specifications

General

Year	2009
Manufacturer	Victory
Model	VISION
Category	Touring
Compression Ratio	9.4:1
Cooling System	Air / oil
Transmission	6-speed
Final Drive	Belt
Front Tire	130/70-R18
Rear Tire	180/60-R16
Engine Type	V-twin, four-stroke
Displacement	1731 cc
Bore x Stroke	101 x 108 mm
Fuel System	Electronic Fuel Injection
Front Suspension	Telescopic fork
Rear Suspension	Single
Front Brakes	Dual 300mm discs, 4-piston calipers
Rear Brakes	Single 300mm disc 2 piston caliper
Seat Height	26.5 inches
Fuel Capacity	22.7 liters / 6.0 US gallons
Wheelbase	65.7 inches
