33: Configuring a GRE interface
_______________________________________________________________________________________________________
_____________________________________________________________________________________________________
© Virtual Access 2017
GW1000 Series User Manual
Issue: 1.9 Page 307 of 350
33.2.1 GRE connection: common configuration - general setup
Figure 152: The GRE common configuration page
Web Field/UCI/Package Option
Web: Protocol of the new interface
UCI: network.<if name>.proto
Opt: proto
Shows the protocol the interface will operate on. GRE should be
currently selected.
Web: Tunnel IP Address
UCI: network.<if name>.ipaddr
Opt: ipaddr
Configures local IP address of the GRE interface.
Web: Mask Length
UCI: network.<if name>.mask_length
Opt: mask_length
Subnet mask, in CIDR notation, to be applied to the tunnel.
Typically '30' for point-to-point tunnels.
