56 D-303222 PowerMaster-10 / PowerMaster-30 Installer's Guide
3.6.3 Configuring GSM-GPRS (IP) - SMS Cellular Connection
The GSM/GPRS module is capable of communicating with the Monitoring station receiver by GPRS, GSM Voice
(analog) or SMS Channels.
Each of the channels can be separately enabled or disabled in order to allow or prohibit the module from using it for
the event reporting. If all channels are enabled, the GSM/GPRS module will always try GPRS first. If fails, it will try
GSM voice. If fails, it will try any other possible method (PSTN Broadband) and only then it will try SMS. Disabling
any of the GSM channels will cause the module to use a different sequence than the one described above.
To configure an option enter the menu, select the option you wish to configure (see
guidance above and in section 3.6.1), then refer to the table below which provides you with detailed
explanations and configuration instructions for each option.
Option Configuration Instructions
Here you determine whether the system will report events to the Monitoring Stations'
PowerManage receivers via the GPRS (IP) Channel. For further information see
section 3.6.4 options 21 & 22.
Option settings: disable (default); enable.
Here you determine whether the system will report events to the Monitoring Stations'
Alarm Format receivers via the GSM Voice (analog) Channel. For further information
see section 3.6.4 option 41.
Option settings: disable (default); enable.
Here you determine whether the system will report events to the Monitoring Stations'
SMS receivers via the SMS Channel. For further information see section 3.6.4 options
26 & 27.
Option settings: disable (default); enable.
Here you enter the name of the APN Access Point used for the internet settings for the
GPRS (up to 40 digits string).
Note: To enter the APN Access Point, use the "String Editor" at the end of this section.
Here you enter the Username of the APN used for GPRS communications (up to 30
digits string).
Note: To enter the Username, use the "String Editor" at the end of this section.
Here you enter the PIN code of the SIM card installed in the GSM module (up to 16
numerical digits).
Note: To enter the numerical PIN code, use the numerical keyboard.
