0mA
1 Devices that are connected between
12V terminal and GND of
PowerMaster-30, that includes internal
GSM and proximity reader.
2 7.2V 1300 mAh, rechargeable NiMH
battery pack, p/n GP130AAH6BMX,
manufactured by GP.
3 9.6V 1800 mAh, rechargeable NiMH
battery pack, p/n GP180AAH8BMX,
manufactured by GP.
4 9.6V 2200 mAh, rechargeable NiMH
battery pack (special order).
Caution! Risk of explosion if battery is
replaced by an incorrect type. Dispose of
used batteries according to the
manufacturer's instructions.
Note: For compliance with UL standards
the battery backup period shall exceed 24
hours and 12 hours for compliance with CE
standards.
Time to Charge
80 % (∼ 13 Hrs) 80 % (∼ 30 Hrs) for all battery types
Optional Backup
Battery Pack
4.8V 2200 mAh, rechargeable NiMH battery
pack, p/n GP230AAHC4YMX, manufactured
by GP
See "Backup Battery Options" table above
Time to Charge
(optional backup
battery pack)
80 % (∼ 24 Hrs)
NA
Wired Detectors
Total (Sum)
Current
NA 36* mA max.
Site External
Siren Current
(EXT)
NA 450* mA max @ 12.5 VDC when powered
by AC/DC (10.5 VDC when in standby
mode)
Site Internal Siren
Current (INT)
NA 450* mA max @ 12.5 VDC when powered
by AC/DC (10.5 VDC when in standby
mode)
* Total PowerMaster-30 output current (of
INT & EXT sirens, PGM output and
detectors) cannot exceed 550 mA.
PGM Current sink to control panel GND 100 mA
max.
Max. external DC voltage +30 VDC
Current sink to control panel GND 100 mA
max.
Max. external DC voltage +15 VDC
High Current /
Short Circuit
Protection
NA All outputs are protected (automatic reset
fuse)
