Making 600E Pump Connections 15
The solvent and sparge tubing lines are on the right side of the pump near the front.
3. Uncoil the tubing and direct it around the right side of the 600E pump.
Flushing Diffuser Filter
1. Attach the filter to a priming syringe with a short length of Teflon tubing.
2. Place the filter in methanol.
3. Pull the syringe handle back to draw methanol through the filter.
4. Expel the methanol into a suitable wash container by pushing the syringe handle
forward.
5. Repeat steps 1 through 4 several times to ensure adequate filter flushing.
Connecting the Eluent Reservoir to the Pump
1. Push a labeled eluent tube through a hole in the appropriate reservoir cap
(Figure 2-7). Push enough tubing through the cap to reach the bottom of the
appropriate eluent reservoir bottle.
Figure 2-7 Eluent Reservoir Diffuser Filter Placement
STOP
Attention: Always flush new solvent filters and diffusers with methanol
before attaching the filters to the eluent and sparge tubing.
