Watlow PM PLUS™ 6 • 121 • Chapter 10 Appendix
CIP Implicit Assembly
Target (PM PLUS) to Originator (Master)
Assembly
Members
Assembly
Class, Instance,
Attribute
Data
Type
Parameter
Parameter
Class, Instance,
Attribute
PLC
Data Type
- - - - Cannot be changed Binary Device Status None BIN
1 0x77, 0x02, 0x01 DINT Analog Input 1, Analog Input Value 0x68, 0x01, 0x01 REAL
2 0x77, 0x02, 0x02 DINT Analog Input 1, Input Error 0x68, 0x01. 0x02 REAL
3 0x77, 0x02, 0x03 DINT Analog Input 2, Analog Input Value 0x68, 0x02, 0x01 REAL
4 0x77, 0x02, 0x04 DINT Analog Input 2, Input Error 0x68, 0x02, 0x02 REAL
5 0x77, 0x02, 0x05 DINT Alarm 1, Alarm State 0x6D, 0x01, 0x09 DINT
6 0x77, 0x02, 0x06 DINT Alarm 2, Alarm State 0x6D, 0x02, 0x09 DINT
7 0x77, 0x02, 0x07 DINT Alarm 3, Alarm State 0x6D, 0x03, 0x09 DINT
8 0x77, 0x02, 0x08 DINT Alarm 4, Alarm State 0x6D, 0x04, 0x09 DINT
9 0x77, 0x02, 0x09 DINT Event Status 1 0x6E, 0x01, 0x05 DINT
10 0x77, 0x02, 0x0A DINT Event Status 2 0x6E, 0x02, 0x05 DINT
11 0x77, 0x02, 0x0B DINT Loop 1 - Control Mode Active 0x97, 0x01, 0x02 DINT
12 0x77, 0x02, 0x0C DINT Loop 1 - Heat Power 0x97, 0x01, 0x0D REAL
13 0x77, 0x02, 0x0D DINT Loop 1 - Cool Power 0x97, 0x01, 0x0E REAL
14 0x77, 0x02, 0x0E DINT Limit State 0x70, 0x01, 0x06 DINT
15 0x77, 0x02, 0x0F DINT Profile Start 0x7A, 0x01, 0x01 DINT
16 0x77, 0x02, 0x10 DINT Profile Action Request 0x7A, 0x01, 0x0B DINT
17 0x77, 0x02, 0x11 DINT Current Profile 0x7A, 0x01, 0x03 DINT
18 0x77, 0x02, 0x12 DINT Current Step 0x7A, 0x01, 0x04 DINT
19 0x77, 0x02, 0x13 DINT Loop 1 - Active Set Point 0x7A, 0x01, 0x05
REAL
20 0x77, 0x02, 0x14 DINT Step Time Remaining 0x7A, 0x01, 0x09
DINT
21 0x77, 0x02, 0x15 DINT None Specified - - - - - - - -
22 0x77, 0x02, 0x16 DINT None Specified - - - - - - - -
23 0x77, 0x02, 0x17 DINT None Specified - - - - - - - -
24 0x77, 0x02, 0x18 DINT None Specified - - - - - - - -
25 0x77, 0x02, 0x19 DINT None Specified - - - - - - - -
26 0x77, 0x02, 0x1A DINT None Specified - - - - - - - -
27 0x77, 0x02, 0x1B DINT None Specified - - - - - - - -
28 0x77, 0x02, 0x1C DINT None Specified - - - - - - - -
29 0x77, 0x02, 0x1D DINT None Specified - - - - - - - -
30 0x77, 0x02, 0x1E DINT None Specified - - - - - - - -
31 0x77, 0x02, 0x1F DINT None Specified - - - - - - - -
32 0x77, 0x02, 0x20 DINT None Specified - - - - - - - -
33 0x77, 0x02, 0x21 DINT None Specified - - - - - - - -
34 0x77, 0x02, 0x22 DINT None Specified - - - - - - - -
35 0x77, 0x02, 0x23 DINT None Specified - - - - - - - -
36 0x77, 0x02, 0x24 DINT None Specified - - - - - - - -
37 0x77, 0x02, 0x25 DINT None Specified - - - - - - - -
38 0x77, 0x02, 0x26 DINT None Specified - - - - - - - -
39 0x77, 0x02, 0x27 DINT None Specified - - - - - - - -
40 0x77, 0x02, 0x28 DINT None Specified - - - - - - - -
The first T to O member above (Device Status) is always present but not counted when configuring the
gateway size using the RUI or EZ-ZONE Configurator software. However, it most always be counted
when configuring the input size of the Master. As an example, if using the DINT comm format in a PLC
and the entire assembly as shown above, the input size would require 41 members.
Although 40 members are built into PM controllers, the RUI allows for a maximum of 20.
