Page #45 background imageLoading...
Page #45 background image
Watlow PM PLUS™ 6 • 45 • Chapter 5: Setup
Setup List
Setup Lists
You will not see every parameter listed here. These vary depending on the features enabled on your device.
Analog Input List
Operations — Setup — Analog Input
Parameter Description Range of Options Default ID*
Analog Input [1,2] The process value of the input. Select instance
1 or 2 if there are two input instances. (With-
out two analog input instances, Analog 1 will
be automatically selected/displayed and Analog
2 will not appear).
Note: Ensure that there is no Input Error (61)
when reading this value using a field bus proto-
col. If an error exists, the last known value prior
to the error will be returned.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
- - - - 4001
Operations — Setup — Analog Input — [Analog Input 1, Analog Input 2]
Sensor Type Analog sensor type wired to this input.
Note: There is no open sensor protection for
process inputs.
Off (62)
Thermocouple (95)
Millivolts (56)
Volts dc (104)
Milliamps dc (112)
RTD 100 Ω (113)
RTD 1,000 Ω (114)
Potentiometer 1 kΩ (155)
Thermistor (229)
Thermocouple
or Thermistor
4005
TC Linearization Thermocouple linearization wired to this input.
B (11)
K (48)
C (15)
N (58)
D (23)
R (80)
E (26)
S (84)
F (30)
T (93)
J (46)
J 4006
RTD Leads Quantity of leads on the RTD wired to this
input.
2 (1)
3 (2)
2 4007
