Watlow PM PLUS™ 6 • 57 • Chapter 5: Setup
Setup Lists
You will not see every parameter listed here. These vary depending on the features enabled on your device.
Low Power Scale Output Digital (1 to 4). The power output will
never be less than the value specified and will
represent the value at which output scaling
begins.
0.0 to 100.0% 0.0% 6009
High Power Scale Output Digital (1 to 4). Power output will never
be greater than the value specified and repre-
sents the value at which output scaling stops.
0.0 to 100.0% 100.0% 6010
Type Output Process (1 or 3). Select whether the
process output operates in volts or milliamps.
Volts (104)
Milliamps (112)
Volts 18001
Function Output Process (1 or 3). Set the type of func-
tion that will drive this output.
Off (62)
Heat (36)
Cool (20)
Duplex (212)
Alarm (6)
Profile Event Out A (233)
Profile Event Out B (234)
Retransmit (213)
Off 18002
Retransmit Source Output Process (1 or 3). Select the value that
will be retransmitted.
Analog Input (142)
Set Point (85)
Current Sample and hold
(22)
Process Value (241)
Analog Input 18003
Function Instance Output Process (1 or 3). Set the instance of
the function selected above.
1 to 4 1 18004
Scale Low Output Process (1 or 3). Set the scale low for
process output in electrical units. This value
in volts or milliamps, corresponds to 0% PID
power output or range low retransmit output.
-100.0 to 100.0 0.00 18009
Scale High Output Process (1 or 3). Set the scale high for
process output in electrical units. This value in
volts or milliamps, corresponds to 100% PID
power output or range high retransmit output.
-100.0 to 100.0 10.00 18010
Range Low Output Process (1 or 3). Set the minimum
value of the retransmit value range in process
units. When the retransmit source is at this
value, the retransmit output will be at its Scale
Low value.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
0.0°F or units
-18°C
18011
Range High Output Process (1 or 3). Set the maximum
retransmit value in process units. When the re-
transmit source is at this value, the retransmit
output is at its Scale High value.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
100.0°F or
units
38.0°C
18012
Calibration Offset Output Process (1 or 3). Set an offset value for
a process output.
-1,999.000 to 9,999.000°F
or units
-1,110.555 to 5,555.000°C
0.0°F or units
0.0°C
18007
Alarm List
Operations — Setup — Alarm — Alarm [1,2,3,4] —
Type Select whether the alarm trigger is a fixed
value or will track the set point.
Off (62)
Process Alarm (76)
Deviation Alarm (24)
Off 9015
