Watlow PM PLUS™ 6 • 50 • Chapter 5: Setup
Setup Lists
You will not see every parameter listed here. These vary depending on the features enabled on your device.
Output Point 8 Set the value mapped to input 8. -1,999.000 to 9,999.000 7.0 34025
Input Point 9 Set the value mapped to output 9. -1,999.000 to 9,999.000 8.0 34016
Output Point 9 Set the value mapped to input 9. -1,999.000 to 9,999.000 8.0 34026
Input Point 10 Set the value mapped to output 10. -1,999.000 to 9,999.000 9.0 34017
Output Point 10 Set the value mapped to input 10. -1,999.000 to 9,999.000 9.0 34027
Process Value List
Operations — Setup — Process Value — [Process Value 1, Process Value 2] —
Function Set the function that will be applied to the
source or sources.
Note: Differential and Ratio not available using
instance 2.
Off (62)
Pressure to Altitude
(1649)***
Square Root (1380)
Differential (1373)
Ratio (1374)
Wet Bulb Dry Bulb (1369)
Vaisala (1648)
Sensor Backup (1201)
Off 26021
Pressure Units*** If Process Value function is set for Pressure
to Altitude units, define units of measure for
conversion.
Pounds per Square Inch
(1671)
Pascal (1674)
Atmosphere (1675)
Millibar (1672)
Torr (1673)
PSI 26028
Altitude Units*** If Process Value function is set for Pressure
to Altitude units, define units of measure for
conversion.
Kilofeet (1677)
Feet (1676)
HFt 26029
Barometric Pressure*** If Process Value function is set for Wet Bulb
/ Dry Bulb, define pressure value used for hu-
midity calculation.
10.0 to 16.0 14.7 26030
Filter Filtering smooths out the output signal of this
function block. Increase the time to increase
filtering.
0.0 to 60.0 seconds 0.0 26026
*** Pressure Altitude calculation is based on the International Standard Atmosphere 1976
Source Value A The value of Source A. Linearization 1 is con-
nected to Source A of Process Value 1. Linear-
ization 2 is connected to Source A of Process
Value 2
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
- - - - 26016
Source Value B View the value of Source B. Linearization 2 is
connected to Source B of Process Value 1.
Linearization 1 is connected to Source B of
Process Value 2
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
- - - - 26017
Offset The offset to be applied to this function's out-
put.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
0 26023
Output Value View the value of this function block's output. -1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
- - - - 26022
