Watlow PM PLUS™ 6 • 47 • Chapter 5: Setup
Setup Lists
You will not see every parameter listed here. These vary depending on the features enabled on your device.
Input Error View the cause of the most recent error. None (61)
Open (65)
Shorted (127)
Measurement Error (140)
Bad Calibration Data (139)
Ambient Error (9)
RTD Error (141)
Fail (32)
- - - - 4002
Digital Bus List
Operations — Setup — Digital Bus (J1939 CAN) —
J1939 Instance Select the instance. 1 to 6 - - - - - - - -
Operations — Setup — Digital Bus (J1939 CAN) — [Digital Bus 1,2,3,4,5,6] —
Units Set the type of units the sensor will measure. Absolute Temperature
(1540)
Relative Temperature
(1541)
Power (73)
Process (75)
Relative Humidity (1538)
None (61)
Absolute Tem-
perature
95005
Input Value View the input value. -1,999.000 to 9,999.000 - - - - 95001
Input Error Selected sensor instance is in error state. None (61)
Open (65)
Shorted (127)
Measurement Error (140)
Bad Calibration Data (139)
Ambient Error (9)
RTD Error (141)
Fail (32)
Math Error (1423)
Not Sourced (246)
Stale (883)
Stale 95002
Output Value View the output value of Digital Bus 1-6. -1,999.000 to 9,999.000 - - - - 95003
CAN ID High Word Digital Bus (1 to 4) 0 to 65,535 0 94023
CAN ID Low Word Digital Bus (1 to 4) 0 to 65,535 0 94022
Encoding Typ Digital Bus (1 to 6) State (2008)
Slots (2009)
Slots 94005
Start Byte Digital Bus (1 to 4) 1 to 8 1.0 94006
Start Bit Digital Bus (1 to 4) 1 to 8 1.0
94007
Signal Length in Bits Digital Bus (1 to 4) 1 to 63 1.0
94008
Scaling Numerator Digital Bus (1 to 4) 1 to 65,535 Instance
1,2,3,6 = 128,
Instance 4,5
= 1
- - - -
Scaling Denominator Digital Bus (1 to 4) 1 to 65,535 Instance
1,2,3,6 =
4096, Instance
4, 5 = 1
- - - -
