Watlow PM PLUS™ 6 • 52 • Chapter 5: Setup
Setup Lists
You will not see every parameter listed here. These vary depending on the features enabled on your device.
Active Function Select the function that will be triggered by a
true state for Digital Inputs 5 to 6.
None (61)
User Set Restore, edge
triggered (227)
Keypad Lockout, level
triggered (217)
Alarm Reset, edge
triggered (6)
Silence Alarms, edge
triggered (108)
Start Step, edge triggered
(1077)
Profile Start/Stop, level
triggered (208)
Start Profile, edge triggered
(196)
Profile Hold/Resume, level
triggered (207)
Profile Disable, level
triggered (206)
Control Loops Off and
Alarms to Non-alarm State,
level triggered (220)
Remote Set Point, level
triggered (216)
Force Alarm to occur, level
triggered (218)
Idle Set Point, level
triggered (107)
Tune, edge triggered (98)
Manual, level triggered (54)
Switch Control Loop Off,
level triggered (90)
TRU-TUNE+
Disable, level
triggered (219)
None 10003
Function Instance Select which Digital Input will be triggered
by a true state.
0 to 40 0 10004
Limit List
Operations — Setup — Limit —
Sides Select the side or sides of the process value to
be monitored.
Both (13)
High (37)
Low (53)
Both 12005
