Watlow PM PLUS™ 6 • 60 • Chapter 5: Setup
Setup Lists
You will not see every parameter listed here. These vary depending on the features enabled on your device.
Source Function C Select the analog source for the ready band. Process Value (241)
None (61)
Analog Input (142)
Linearization (238)
Process Value 31031
Source Instance C Select an instance of Function C. 1 to 24 1 31033
Source Function D Select which input will acknowledge the ready
band.
Function Key (1001)
None (61)
Digital I/O (1142)
Function Key 31032
Source Instance D Select an instance of Function D. 1 to 24 7 31034
Time Remaining Display the time remaining on the timer. 00:00 to 99:59 7 31021
Ready Band State Display whether the process value is in the
ready band.
Yes (106)
No (59)
- - - - 31022
Ready Band Set difference of process value to the closed-
loop timer set point to be in the ready band.
0.000 to 9999.000°F or
units
0.000 to 5555.000°C
5.000 31023
Time Format Select the time format. Time Minutes:Seconds
(1943)
Time Hours:Minutes (1944)
Time Minutes:
Seconds
31024
Hours Set the timer period hours. 0 to 99 0 31025
Minutes Set the timer period minutes. 0 to 59 0 31026
Seconds Set the timer period seconds. 0 to 59 10 31027
Closed Loop Timer Set
Point ("Closed Loop
Timer SP")
Set the set point that will be in effect during
the timer period.
-1999.000 to 9999.000°F
or units
-1110.555 to 5555.000°C
75 31028
Signal Time Set the period of time that a signal output to
be activated after the timer period is complete.
Assign a digital output for this function in
Timer Event Output 3.
1 to 3600 Seconds 1 31045
Math List
Operations — Setup — Math —
Source Value A Math (1)
View the value of Source A.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
--- 25016
Source Value B Math (1)
View the value of Source B.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
--- 25017
Source Value E View the value of Source E. Off (62)
On (63)
--- 25020
Offset Set an offset to be applied to this function's
output.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
--- 25023
Function Set the operator that will be applied to the
sources.
Off
Process Scale
Deviation Scale
Off 25021
