Watlow PM PLUS™ 6 • 120 • Chapter 10 Appendix

CIP Implicit Assemblies

CIP Implicit Assembly

Originator (Master) to Target (PM PLUS)

Assembly

Members

Assembly

Class, Instance,

Attribute

Data

Type

Parameter

Class, Instance,

Attribute

PLC

Data Type

1 0x77, 0x01, 0x01 DINT Loop 1 - Control Mode 0x97, 0x01, 0x01 DINT

2 0x77, 0x01, 0x02 DINT Loop 1 - Set Point 0x6B, 0x01, 0x01 REAL

3 0x77, 0x01, 0x03 DINT Loop 1 - Manual Power 0x6B, 0x01, 0x02 REAL

4 0x77, 0x01, 0x04 DINT Alarm 1 - High Set Point 0x6D, 0x01, 0x01 REAL

5 0x77, 0x01, 0x05 DINT Alarm 1 - Low Set Point 0x6D, 0x01, 0x02 REAL

6 0x77, 0x01, 0x06 DINT Alarm 2 - High Set Point 0x6D, 0x02, 0x01 REAL

7 0x77, 0x01, 0x07 DINT Alarm 2 - Low Set Point 0x6D, 0x02, 0x02 REAL

8 0x77, 0x01, 0x08 DINT Alarm 3 - High Set Point 0x6D, 0x03, 0x01 REAL

9 0x77, 0x01, 0x09 DINT Alarm 3 - Low Set Point 0x6D, 0x03, 0x02 REAL

10 0x77, 0x01, 0x0A DINT Alarm 4 - High Set Point 0x6D, 0x04, 0x01 REAL

11 0x77, 0x01, 0x0B DINT Alarm 4 - Low Set Point 0x6D, 0x04, 0x02 REAL

12 0x77, 0x01, 0x0C DINT Profile Action Request 0x7A, 0x01, 0x0B DINT

13 0x77, 0x01, 0x0D DINT Profile Start 0x7A, 0x01, 0x01 DINT

14 0x77, 0x01, 0x0E DINT Loop 1 - Heat Proportional Band 0x97, 0x01, 0x06 REAL

15 0x77, 0x01, 0x0F DINT Loop 1 - Cool Proportional Band 0x97, 0x01, 0x07 REAL

16 0x77, 0x01, 0x10 DINT Loop 1 - Time Integral 0x97, 0x01, 0x08 REAL

17 0x77, 0x01, 0x11 DINT Loop 1 - Time Derivative 0x97, 0x01, 0x09 REAL

18 0x77, 0x01, 0x12 DINT Loop 1 - Heat Hysteresis 0x97, 0x01, 0x0B REAL

19 0x77, 0x01, 0x13 DINT Loop 1 - Cool Hysteresis 0x97, 0x01, 0x0C REAL

20 0x77, 0x01, 0x14 DINT Loop 1 - Dead Band 0x97, 0x01, 0x0A REAL

21 0x77, 0x02, 0x15 DINT None Specified - - - - - - - -

22 0x77, 0x02, 0x16 DINT None Specified - - - - - - - -

23 0x77, 0x02, 0x17 DINT None Specified - - - - - - - -

24 0x77, 0x02, 0x18 DINT None Specified - - - - - - - -

25 0x77, 0x02, 0x19 DINT None Specified - - - - - - - -

26 0x77, 0x02, 0x1A DINT None Specified - - - - - - - -

27 0x77, 0x02, 0x1B DINT None Specified - - - - - - - -

28 0x77, 0x02, 0x1C DINT None Specified - - - - - - - -

29 0x77, 0x02, 0x1D DINT None Specified - - - - - - - -

30 0x77, 0x02, 0x1E DINT None Specified - - - - - - - -

31 0x77, 0x02, 0x1F DINT None Specified - - - - - - - -

32 0x77, 0x02, 0x20 DINT None Specified - - - - - - - -

33 0x77, 0x02, 0x21 DINT None Specified - - - - - - - -

34 0x77, 0x02, 0x22 DINT None Specified - - - - - - - -

35 0x77, 0x02, 0x23 DINT None Specified - - - - - - - -

36 0x77, 0x02, 0x24 DINT None Specified - - - - - - - -

37 0x77, 0x02, 0x25 DINT None Specified - - - - - - - -

38 0x77, 0x02, 0x26 DINT None Specified - - - - - - - -

39 0x77, 0x02, 0x27 DINT None Specified - - - - - - - -

40 0x77, 0x02, 0x28 DINT None Specified - - - - - - - -

Although 40 members are built into PM controllers, the RUI allows for a maximum of 20.
