Watlow PM PLUS™ 6 • 61 • Chapter 5: Setup
Setup Lists
You will not see every parameter listed here. These vary depending on the features enabled on your device.
Source Function E Set the type of function that will be used for
this source.
None
Function Key
Digital I/O
None 25005
Source Instance E Set the instance of the function selected
above.
1 to 12 1 25010
Scale Low This value corresponds to Output Range Low. -1,999.000 to 9,999.000 0.0 25024
Scale High This value corresponds to Output Range High. -1,999.000 to 9,999.000 1.0 25025
Range Low This value corresponds to Input Scale Low. -1,999.000 to 9,999.000 0.0 25026
Range High This value corresponds to Input Scale High. -1,999.000 to 9,999.000 1.0 25027
Filter Filtering smooths out the output signal of this
function block. Increase the time to increase
filtering.
0 to 60 seconds 0.0 25028
Special Output Function
Operations — Setup — Special Output Function —
Function Set the function to match the device it will
operate.
Off (62)
Motorized Valve (1508)
Compressor Control (1506)
Off 35009
Source Function A Set the type of function that will be used for
this source.
None (61)
Power (73)
Heat Power (160)
Cool Power (161)
None 35001
Source Instance A Set the instance of the function selected
above.
1 to 2 1 35003
Source Function B Set the type of function that will be used for
this source.
None (61)
Power (73)
Heat Power (160)
Cool Power (161)
None 35002
Source Instance B Set the instance of the function selected. 1 to 2 1 35004
Input A Turn On Compressor 1 power on level. -100.00 to 100.00% 0 35018
Input A Turn Off Compressor 1 power off level. -100.00 to 100.00% 5 35019
Input B Turn On Compressor 2 power on level. -100.00 to 100.00% 0 35020
Input B Turn Off Compressor 2 power off level. -100.00 to 100.00% 5 35021
Minimum On Time At a minimum stay on specified amount of
time.
0 to 9,999 seconds 20 35022
Minimum Off Time At a minimum stay off specified amount of
time.
0 to 9,999 seconds 20 35023
Valve Travel Time The amount of time it takes the valve to fully
open and then fully close.
10 to 9,999 seconds 120 35024
Dead Band Output power needs to change by specified
level prior to turning on.
1.0 to 100.0% 2 35025
Time Delay If requested power is 0.0% for longer than the
specified Time Delay, the compressor will shut
off.
0 to 9,999 seconds 0 35026
