Watlow PM PLUS™ 6 • 59 • Chapter 5: Setup
Setup Lists
You will not see every parameter listed here. These vary depending on the features enabled on your device.
Clear Alarm Clears the alarm instance Clear (0)
Ignore (204)
- - - - 9013
Silence Alarm Silences the alarm instance. If an alarm is
setup to silence alarm when active the display
will state this. Do not mistake this param-
eter for "Operations - Setup - Alarm - Alarm
[1,2,3,4] - Silencing" which turns the ability to
silence alarms on or off.
Silence (1010) - - - - 9014
Alarm State Current state of alarm Startup (88)
None (61)
Blocked (12)
Alarm low (8)
Alarm high (7)
Error (28)
- - - - 9009
Current List
Operations — Setup — Current —
Sides Select which side or sides will be monitored. Off (62)
High (37)
Low (53)
Both (13)
off 15005
Indicate Reading Use to display solid-state relay (SSR) failure
and heater failure messages.
No (59)
Yes (106)
no 15004
Input Detection Thresh-
old
For factory adjustment only. 3 to 59 9 15012
Input Scaling Adjust scaling to match the transformer's high
range.
0 to 9,999.000 50.0 15022
Heater Offset Calibrate the current reading with an offset
value.
-9,999.000 to 9,999.000 0.0 15011
Monitored Output Select which output instance the current trans-
former will monitor.
1 to 12 1 15019
High Set Point Set the current value that will trigger a high
heater error state.
-1,999.000 to 9,999.000 50.0 15008
Low Set Point Set the current value that will trigger a low
heater error state.
-1,999.000 to 9,999.000 0.0 15009
Timer List
Operations — Setup — Timer [1] —
Timer Enable Enable the timer function. Yes (106)
No (59)
Yes 31029
Timer Start Method Select what will start the timer. Immediate (1049)
Ready Band (1942)
Ready Ack (1950)
Power (73)
Immediate 31030
Source Function A Select which input will start or terminate the
timer.
Function Key (1001)
None (61)
Digital I/O (1142)
Function Key 31001
Source Instance A Select an instance of Function A. 1 to 24 8 31003
