Watlow PM PLUS™ 6 • 62 • Chapter 5: Setup
Setup Lists
You will not see every parameter listed here. These vary depending on the features enabled on your device.
Function Key
Operations — Setup — Function Key —
Active Level The Function Key will always power up in the
low state.Pressing the Function Key will toggle
the selected action.
High (37)
Low (53)
High 10001
Action Function Function Key (1 to 2)
Program the EZ Key to trigger an action.
Functions respond to a level state change or
an edge level change.
None (61)
Remote Set Point (216)
User Set Restore, edge
triggered (227)
Keypad Lockout, level
triggered (217)
Alarm Reset, edge triggered
(6)
Silence Alarms, edge
triggered (108)
Control Loops Off and
Alarms to Non-alarm State,
level triggered (220)
Force Alarm to occur, level
triggered (218)
Idle Set Point, level
triggered (107)
Tune, edge triggered (98)
Manual, level triggered (54)
Switch Control Loop Off,
level triggered (90)
TRU-TUNE+® Disable, level
triggered (219)
Profile Disable, level
triggered (206)
Profile Hold/Resume, level
triggered (207)
Start Profile, edge triggered
(196)
Profile Start/Stop, level
triggered (208)
Start Step (1077)
None 10003
Function Instance Function Key (1 to 2)
Select which instance the EZ Key will affect.
If only one instance is available, any selection
will affect it.
0 to 40 0 10004
Global List
Operations — Setup — Global —
Display Units Select which scale to use for temperature. °F (30)
°C (15)
°F 3005
Language Select which language to be used on for the
display
English (255)
German (256)
Spanish (259)
English 3037
AC Line Frequency Set the frequency to the applied ac line power
source.
50 Hz (3)
60 Hz (4)
60 Hz 1034
Ramping Type Select the way the profile intervals change the
ramping set point.
Time (143)
Rate (81)
Time 22038
