Watlow PM PLUS™ 6 • 55 • Chapter 5: Setup
Setup Lists
You will not see every parameter listed here. These vary depending on the features enabled on your device.
Input Error Power What the controller outputs will do when an
input error switches control to manual mode.
Off, sets output power to
0% (62)
Bumpless transfer, main-
tains same output power,
if it was less than 75% and
stable, otherwise 0% (14)
Fixed Power, sets output
power to Fixed Power set-
ting (54)
User, sets output power to
last open-loop set point the
user entered (100)
User 7013
Fixed Power Manual output power level that will take effect
if an input error failure occurs while User Fail-
ure Action is set to Fixed Power.
Set Point Open Loop Limit
Low to Set Point Open Loop
Limit High (Setup Page)
0.0 7011
OpLoop Detect Enable Open Loop Detect Enable. Select Yes to de-
tect conditions that prevent the process from
changing in specified time frame by a specified
amount when PID power is at 100%. An open
loop detect error will disable the control loop.
No (59)
Yes (106)
No 8039
OpLoop Detect Time Open Loop Detect Time. Process must deviate
by the Open Loop Detect Deviation value in the
specified time, while at 100% PID power, oth-
erwise an Open Loop Detect event is triggered.
0 to 3,600 seconds 240 8040
OpLoop Detect Dev Open Loop Detect Deviation. Process must
deviate by this value in the Open Loop Detect
Time while at 100% PID power to prevent an
open loop error.
-1,999.000 to 9,999.000°F
or units
-1,110.555 to 5,555.000°C
10.0°F or units
6.0°C
8041
Ramp Action Select when the controller's set point will ramp
to the defined end set point.
Off (62)
Startup (88)
Set Point Change (85)
Both (13)
Off 7014
Ramp Scale Scale of the ramp rate. Hours (39)
Minutes (57)
Minutes 7015
Ramp Rate Rate for the set point ramp. Set the time units
for the rate with the Ramp Scale parameter.
0.0 to 9,999.000°F or units
0.0 to 5,555.000°C
1.0°F or units
1.0°C
7017
Minimum Set Point Minimum value of the closed loop set point
range.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
-1,999°F or
units
-1,128°C
7003
Maximum Set Point Maximum value of the closed loop set point
range.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
9,999°F or
units
5,537°C
7004
Set Point Closed loop set point that the controller will
automatically control to.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
75.0°F or
units
24.0°C
7001
Idle Set Point Closed loop set point that can be triggered by
an event state.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
75.0°F or
units
24.0°C
7009
Minimum Manual
Power
Minimum value of the open-loop set point
range.
-100.0 to 100.0% -100 7005
