Watlow PM PLUS™ 6 • 66 • Chapter 5: Setup
Setup Lists
You will not see every parameter listed here. These vary depending on the features enabled on your device.
IP Fixed Addr Part1 Set the IP address of this module. Each device
on the network must have a unique address.
0 to 255 169 17014
IP Fixed Addr Part2 IP Fixed Address Part 2. Set the IP address of
this module. Each device on the network must
have a unique address.
0 to 255 254 17015
IP Fixed Addr Part3" IP Fixed Address Part 3. Set the IP address of
this module. Each device on the network must
have a unique address.
0 to 255 1 17016
IP Fixed Addr Part4 IP Fixed Address Part 4. Set the IP address of
this module. Each device on the network must
have a unique address.
0 to 255 1 17017
IP Fixed Subnet Prt1 the IP subnet mask part 1 0 to 255 255 17020
IP Fixed Subnet Prt2 Set the IP subnet mask part 2 0 to 255 255 17021
IP Fixed Subnet Prt3 Set the IP subnet mask part 3 0 to 255 0 17022
IP Fixed Subnet Prt4 Set the IP subnet mask part 4 0 to 255 0 17023
IP Fixed Subnet Prt5 Set the IP subnet mask part 5 0 to 255 0 17024
IP Fixed Subnet Prt6 Set the IP subnet mask part 6. 0 to 255 0 17025
Fixed IP Gateway Part
1
Used for the purpose of sending and receiving
messages from another network.
0 to 255 0 17026
Fixed IP Gateway Part
2
Used for the purpose of sending and receiving
messages from another network.
0 to 255 0 17027
Fixed IP Gateway Part
3
Used for the purpose of sending and receiving
messages from another network.
0 to 255 0 17028
Fixed IP Gateway Part
4
Used for the purpose of sending and receiving
messages from another network.
0 to 255 0 17029
Fixed IP Gateway Part
5
Used for the purpose of sending and receiving
messages from another network.
0 to 255 0 17030
Fixed IP Gateway Part
6
Used for the purpose of sending and receiving
messages from another network.
0 to 255 0 17031
Modbus
®
TCP Enable Activate Modbus
®
TCP.
Yes (106)
No (59)
Yes 17041
EtherNet/IP™ Enable Activate Ethernet/IP™.
Yes (106)
No (59)
Yes 17042
EtherNet/IP™ Output
Assembly (" CIP Targe-
t2Orig Qty")
When using EtherNet/IP set the CIP Implicit
Assembly Output Member Quantity
1 to 40 40 24009
EtherNet/IP™ Input
Assembly (" CIP Orig-
2Target Qty")
When using EtherNet/IP set the CIP Implicit
Assembly Input Member Quantity
1 to 40 40
24010
Display Units Select the scale for temperature passed over
communications port 2.
°F (30)
°C (15)
°F 17050
Non-volatile Save If set to Yes all values written to the control
will be saved in EEPROM. The EEPROM allows
for approximately one million writes.
Yes (106)
No (59)
No 17051
Note: When changing IP address, the control power must be cycled for the new address to take effect.
