Watlow PM PLUS™ 6 • 72 • Chapter 6: Profiles
Profile List Parameters
Operations — Profile —
Display
Parameter Name
Description
Range Default ID
Target Set Point
Loop 2
When Step Type is Time enter the closed loop set
point for loop 2 to ramp to for this step.
-1,999.000 to 9,999.000°F or units
-1,128 to 5,537.000°C
0.0°F or
units
-18°C
21028
Hours Select the hours (plus Minutes and Seconds) for a
timed step, i.e. Time, Soak, or Wait for Time..
0 to 9999
0 21003
Minutes Enter Minutes (plus Hours and Seconds) for a
timed step, i.e. Time, Soak, or Wait for Time.
0 to 59
0 21004
Seconds Enter Seconds (plus Hours and Minutes) for a
timed step, i.e. Time, Soak, or Wait for Time.
0 to 59
0 21005
Rate When Step Type is Rate, enter the rate for ramping
in degrees or units per minute.
0 to 9,999.000°F or units per minute
0 to 5,555.000°C per minute
0.0 21006
Wait For Process Enter the analog input specified by Wait For Pro-
cess 1 that must be met in a Wait for Process or
Wait for Both step before proceeding in profile.
1 or 2
1 21015
Wait For Process 1 Enter wait for process value on analog input speci-
fied by Wait For Process Instance in a Wait for pro-
cess or Wait for Both step before proceeding.
-1,999.000 to 9,999.000°F or units
-1,128.000 to 5,537.000°C
0.0°F or
units
-18.0°C
21011
Wait Event 1 Select the event state that must be satisfied during
a Wait for Event or Wait for Both step. Wait Event 1
is mapped to DIO 5.
Off (62)
On (63)
None (61)
Off 21009
Wait Event 2 Select the event state that must be satisfied during
a Wait for Event or Wait for Both step. Wait Event 2
is mapped to DIO 6.
Off (62)
On (63)
None (61)
Off 21010
Jump Step When Step Type is Jump, this specifies which step
to jump back to. Jump Step must be a lower step
number than the current step number.
1 to 40
0 21012
Jump Count When Step Type is Jump, this specifies the number
of jumps to repeat. A value of 0 creates an infinite
loop. Loops can be nested four deep.
0 to 9,999
0 21013
End Type When Step Type is End, this specifies what the con-
troller will do when this profile ends.
Off Control Mode set to Off (62)
Hold Hold last closed-loop set point
in the profile (47)
User User, reverts to previous set
point (100)
Off 21014
Event 1 When Step Type is not Unused Step, select whether
Event Output 1 or 2 is on or off during this step.
Off (62)
On (63)
Off 21007
Event 2 When Step Type is not Unused Step, select whether
Event Output 1 or 2 is on or off during this step.
Off (62)
On (63)
Off 21008
