CHAPTER 8 - OPTIONS AND ACCESSORIES
Figure 8.4 - Braking resistor connection (only for the models
7.3 and 10.0 A/200-240 V and 4.0 A/110-127 V single-phase and
10.0 A and 15.2 A/200-240 V three-phase)
Motor
Input power
supply
Contactor
Control
Voltage
Thermal
Relay
Thermostat
Braking
Resistor
U
V
W
L/L1
N/L2
BR +UD
L3
