CHAPTER 6 - DETAILED PARAMETER DESCRIPTION
Range
[Factory Setting]
Parameter Description / Notes
0.1 to 999 s
[ 5.0 s ]
0.1 s (< 100);
1 s (> 99.9)
0.1 to 999 s
[ 10.0 s ]
0.1 s (< 100);
1 s (> 99.9)
0.1 to 999 s
[ 5.0 s ]
0.1 s (< 100);
1 s (> 99.9)
0.1 to 999 s
[ 10.0 s ]
0.1 s (< 100);
1 s (> 99.9)
This set of parameters defines the times to accelerate
linearly from zero up to the rated frequency and to
decelerate linearly from the rated frequency down to
zero.
The rated frequency is defined by parameter P145 .
When factory setting is used, inverter always follows
the time defined in P100 and P101.
If Ramp 2 should be used, where the acceleration and
deceleration times follow the values programmed at
P102 and P103, use a digital input. See parameters
P263 to P265.
Depending on the load inertia, too short acceleration
times can disable the inverter due to overcurrent (E00).
Depending on the load inertia, too short deceleration
times can disable the inverter due to overvoltage
(E01). For more details, refer to P151.
P104 0 to 2
S Ramp [ 0 - Inactive ]
-
The ramp S reduces mechanical stress during the the
load acceleration and deceleration.
P100
Acceleration
Time
P101
Deceleration
Time
P102
Acceleration
Time
Ramp 2
P103
Deceleration
Time
Ramp 2
P104
0
1
2
Ramp S
Inactive
50 %
100 %
P040 0.0 to 999
Variable Process [ - ]
-
Indicates the value of the process variable used as
PID regulator feedback, in percent (%).
The PID function is only available from V.2.00 software
version.
The unit scale can be changed through P528.
See detailed description of the PID regulator in Special
Functions Parameters item.
Table 6.1 - Ramp configuration
