WEG CFW-10 - Chapter 9 Technical Specifications; Power Data

108
CHAPTER 9
TECHNICAL SPECIFICATIONS
This chapter describes the technical specifications (electrical and
mechanical) of the CFW-10 inverter series.
9.1 POWER DATA
AC Input Specifications:
Voltage: -15 %, +10 % (with loss of motor efficiency);
Frequency : 50/60 Hz (± 2 Hz);
Overvoltage: Category III (EN 61010/UL 508C);
Transient voltages according to Category III.
Minimum line impedance: variable according to inverter model. Refer
to Section 8.2.
Power-up: max. 10 ON/OFF cycles per hour.
9.1.2 Power Supply: 200/240 V – Three-phase
9.1.1 Power Supply: 200/240 V – Single-phase
Model: Current (A) / Voltage (V)
1.6/
200-240
2.6/
200-240
4.0/
200-240
7.3/
200-240
10.0/
200-240
15.2/
200-240
Power (kVA)
(1)
0.6 1.0 1.5 2.8 3.8 5.8
Rated Output Current (A)
(2)
1.6 2.6 4.0 7.3 10.0 15.2
Max. Output Current (A)
(3)
2.4 3.9 6.0 11.0 15.0 22.8
Power Supply Three-phase
Rated Input Current (A) 2.0 3.1 4.8 8.6 12.0 18.0
Switching Frequency (kHz) 10 10 10 5 5 2.5
Max. Motor Power (CV)
(4) (5)
0.25 HP/
0.18 kW
0.5 HP/
0.37 kW
1 HP/
0.75 kW
2 HP/
1.5 kW
3 HP/
2.2 kW
5 HP/
3.7 kW
Watt Losses (W) 30 35 50 90 100 160
Rheostatic Braking No No No No Yes Yes
Model: Current (A) / Voltage (V)
1.6/
200-240
2.6/
200-240
4.0/
200-240
7.3/
200-240
10.0/
200-240
Power (kVA)
(1)
0.6 1.0 1.5 2.8 3.8
Rated Output Current (A)
(2)
1.6 2.6 4.0 7.3 10.0
Max. Output Current (A)
(3)
2.4 3.9 6.0 11.0 15.0
Power Supply Single-phase
Rated Input Current (A) 3.5 5.7 8.8 16.0 22.0
Switching Frequenc y (kHz) 10 10 10 5 5
Max. Motor Output (CV)
(4) (5)
0.25 HP/
0.18 kW
0.5 HP/
0.37 kW
1 HP/
0.75 kW
2 HP/
1.5 kW
3 HP/
2.2 kW
Watt Losses (W ) 30 35 50 90 100
Rheostatic Braking No No No Yes Yes
